Stainless Steel Filter Mesh Specification：
Mesh/Inch | Wire Diameter | Aperture | Open Area | Weight | ||
Inch | MM | Inch | MM | |||
1x1 | .080 | 2.03 | .920 | 23.37 | 92.0 | 2.0 |
2X2 | .063 | 1.60 | .437 | 11.10 | 87.4 | 2.5 |
3X3 | .054 | 1.37 | .279 | 7.09 | 83.8 | 2.7 |
4X4 | .047 | 1.19 | .203 | 5.16 | 81.2 | 2.7 |
5X5 | .041 | 1.04 | .159 | 4.04 | 79.5 | 2.6 |
10X10 | .025 | .64 | .075 | 1.91 | 74.9 | 2.0 |
12X12 | .020 | .508 | .063 | 1.60 | 75.9 | 1.5 |
14X14 | .020 | .508 | .051 | 1.30 | 71.9 | 1.8 |
16X16 | .018 | .457 | .0445 | 1.13 | 71.2 | 1.6 |
18X18 | .017 | .432 | .0386 | .98 | 69.4 | 1.6 |
20X20 | .020 | .240 | .0300 | .76 | 76.0 | .56 |
20X20 | .016 | .330 | .0340 | .86 | 72.2 | 1.1 |
30X30 | .0120 | .305 | .0213 | .54 | 63.9 | 1.4 |
30X30 | .0094 | .240 | .0243 | .62 | 72.1 | .84 |
40X40 | .0100 | .254 | .0150 | .38 | 59.9 | 1.3 |
50X50 | .0055 | .140 | .0145 | .368 | 72.4 | .48 |
60X60 | .0047 | .120 | .0120 | .303 | 71.6 | .42 |
60X60 | .0059 | .150 | .0107 | .273 | 64.5 | .65 |
80X80 | .0055 | .140 | .0069 | .117 | 45.5 | .76 |
100X100 | .0045 | .114 | .0055 | .140 | 55.1 | .59 |
100X100 | .0040 | .102 | .0060 | .152 | 59.8 | .49 |
120X120 | .0028 | .070 | .0057 | .147 | 67.7 | .29 |
150X150 | .0024 | .060 | .0043 | .110 | 64.7 | .26 |
150X150 | .0028 | .070 | .0039 | .100 | 58.8 | .38 |
165X165 | .0019 | .050 | .0041 | .104 | 67.5 | .20 |
180X180 | .0019 | .050 | .0035 | .091 | 64.5 | .22 |
180X180 | .0024 | .060 | .0031 | .081 | 57.4 | .32 |
200X200 | .0019 | .050 | .0030 | .077 | 60.6 | .24 |
200X200 | .0024 | .060 | .0026 | .067 | 52.7 | .35 |
250X250 | .0016 | .040 | .0024 | .0616 | 60.6 | .20 |
270X270 | .0016 | .040 | .0021 | .0540 | 57.4 | .21 |
300X300 | .0016 | .040 | .0018 | .0450 | 53.5 | .23 |
325X325 | .0014 | .035 | .0017 | .0432 | 55.3 | .20 |
400X400 | .0012 | .030 | .0013 | .0335 | 52.7 | .18 |
500X500 | .0009 | .025 | .0010 | .0258 | 50.7 | .15 |
635X635 | .0007 | .018 | .0008 | .022 | 55.0 | .10 |
Mesh Tips
The distinctions between the stainless steel material:
Type 304 is often referred to as "18-8" ( 18% chromium, 8% nickel ) with the basic stainless alloy most commonly utilized for wire cloth weaving. It withstands outdoor exposure without rusting and resists oxidation at an elevated temperature up to 1400 Degrees Fahrenheit. Type 304 L is very similar to T-304.The difference between Type 304 and Type 304 L is the reduced carbon content.
Type 316 is stabilized by the addition of 2% molydbenum and an "18-8" alloy. It has better resistance to corrosion than the other chromium-nickel stainless steels where brines, sulphur-bearing water or halogen salts(such as chlorides) are present. A valuable property of T-316 has high creep strength at elevated temperatures. Other mechanical properties and fabricating characteristics are similar to T-304.Type 316 L is very similar to T-316. The difference between Type 316 and Type 316 L is on the reduced carbon content that is for wire cloth weaving and secondary welding characteristics.
As a supplier of stainless steel wire mesh for many different industries and applications, Resen produces a wide variety of woven wire meshes. Our production program for square mesh ranges in aperture sizes from 0.025 mm to 14 mm. And in addition to our standard program, which is always readily available in stock, we also run lots of special productions for customer-specific applications.
There are many requirements on fine filtration by using micronic meshes with filter grades(at least 1 µm).Also for that range of filtermedia, stock productions and customer specific productions are combined together.And the plain weave and twilled dutch weave used in this field, as well as the corresponding support meshes, are also a part of our needs-oriented warehousing program.
Depending on the application, the production width is up to 3 m. For filtrating high viscous media,Resen produces Optimized Plain Dutch Weave filtermedia with filter grades ranging from 10 µm up to 80 µm.This is supplied by rolls or strips ready for final fabrication in final production steps in many cases .
This filament-wire connection made of stainless steel offers two advantages,that is, high porosity with absolute homogeneous pore structure and high mechanical stability. Retention rates are ranging from 3 µm up to 100 µm. High mechanical strength coupled with flexibility does allow highly efficient surface and depth filtration with a single filter media.
Choosing Material of Discs:
Material of Wire mesh:304,304L,316,316L;other materials are available for the individual customers.
Standard widths 1020mm and 1220mm which are ex-stock or at short notice are considered as a production run. Other widths available on request.
Standard roll lengths 15 m and 30 m are dependent upon specification. Sections cut to size are available in all sizes and shapes.
County Resen Screenes are used worldwide for their high performance.
Characteristics:
Accuracy of weave;
Regularity;
High stability;
Rigidity;
Corrosion resistance;
Thermal resistance;
Resistance to moisture;
Optimum flow rates;
Narrow pore size distribution;
Precise alignment of filter pores;
Excellent resistance to abrasion;
Easy to clean;
Excellent levels of plasticity;
Chemical and thermal resistance;
Smooth surface structure;
High levels of reliability.
Resen filter cloths are used in:
Pressure filters for fine filtration in hydraulic steering equipment;
Oil and fuel filters ressure and vacuum filters (disc, cell and drum filters)
As porous media for fluidised beds
Pre-coat filters;
Filter candles;
Protection of steering and fuel injection nozzles;
Insulation/sound attenuation (e.g. aircraft engines).
In the following industrial sectors：
Air and space travel;
Automotive industry;
Petrochemicals;
Chemical and pharmaceutical industry/Biotechnology;
Medical science;
Food and beverage industry;
Plastics industry;
Environmental technology.
Filter Discs and Wire Mesh Discs are made of stainless steel woven wire mesh and wire cloth. The material is AISI316L. Pack filters and wire mesh discs are mainly used in pharmacy, chemicals, chemical fibers, etc.
Major filter materials available for packing filters and wire mesh discs:stainless steel woven wire cloth, stainless steel sintered web, phosphate bronze wire cloth and brass wire cloth, etc.
Shapes: Round,rectangle elliptical,other shapes.etc.
Disc filters are provided in different shapes: Single piece or multiple layered.
Marginal materials for disc filters:stainless steel,aluminum and nickel-plated copper.
Sizes: We can supply the sizes by the customers' specific requirements.
Applications of Filter Discs: Filter discs are mainly used in the absorption, evaporation and filtration process in petroleum, chemical, medicine, metallurgy, machinery, ship and automobiles to delete the mist drop or liquid foam; used as air filter in cars and trucks,etc.
Special specifications can be produced by the customer's requirements.
